The World’s First Hydrofoil Bike
Exceptional performance and all water-terrain capabilities elevate the XE-1 into a class of its own. A sporty design is complimented by truly responsive riding dynamics and seamlessly integrated technology.
Specifications
Electric Motor & Battery
Clever technology. Ultra simple to use. This waterproof duo is designed to push the limits of what’s possible on water. The motor has proven resilient against rigorous maritime tests yet produces no more than a quiet hum and inflicts zero harm on the environment.
Features
Fully submersible IPX8 rated battery housing system.
Easy access charging connector with a 4 hour charge time
IPX8 rated electric motor
460 watts of pedal assist power
Up to 4 hours of riding time on the lowest assist level and 1.5 hours on maximum assist Please note, estimated battery run time may vary depending on the weight of the rider, weather conditions, and level of assist.
Chassis & Gears
Resilient against saltwater and corrosion. The Hydrofoiler’s frame and gears are packed full of ingenious design details that stay true to the simplicity of a beautifully crafted bike.
Features
Aircraft-grade, TIG-welded 6061-T6 aluminium frame
Hybrid drivetrain with industry standard components for easy replacement
Buoyancy modules designed to streamline the Hydrofoiler both above and below water
Easy maintenance crank-set sub-assembly, gearbox sub-assembly, and the propeller/shaft sub-assembly
Carbon Fiber Foils
This combination is impeccably tuned. Striking a perfect balance between stability and manoeuvrability in all types of water-terrain.
Features
Foil tip design minimises drag and extends effective wingspan
Rear wingspan measures 6.5ft. Front wing, 4ft
General purpose foils. Suitable for lakes, rivers, and the ocean
Modular design for easy assembly and in-car transport
Bluetooth Connectivity
All Manta5 Hydrofoiler XE-1’s come standard with the GARMIN® eBike Remote. Rugged, compact and lightweight and effectively cycle between the 7 levels of motor assistance. With multiple compatible devices (30+) make use of Manta5’s free Datafields on the Connect IQ Store.
Riders Can Track
Distance
Speed
Ride time
Heart rate
Battery charge level
Electric assist level
* More features to come
Frame
CONSTRUCTION: 6061-T6 Aluminium
BUOYANCY: EPS/PC modules X 4, 250N Net buoyancy
Drivetrain
CHAIN DRIVE: Single speed
CHAINRING: 42T 104PCD (Aluminium 7075)
REAR SPROCKET: Custom 16T Duplex (Marine grade)
CHAIN: Custom Marine Grade
TOP GEARBOX: Custom IPX8 rated Aluminium 90 degree bevel
DRIVESHAFT: Aluminium
BOTTOM GEARBOX: Custom IPX8 rated Aluminium 73 degree bevel
PROPELLER SHAFT: Stainless Steel 316
PROPELLER: Carbon Fibre reinforced Nylon
Foils
CONSTRUCTION: Carbon fibre, hand-built
REAR FOIL: wingspan 6’6” (2 m)
FRONT FOIL: wingspan 3’11” (1.2 m)
REAR FOIL CONNECTION: Custom 6061-T6 Tapered Shoe
E-System
MOTOR: Custom MPF mid-drive motor, water-proof to IPX8 rating
POWER: 460 watts
CONTROL: GARMIN eBike Remote, 7 pedal assist levels
Battery
CHEMISTRY: Lithium-ion
CAPACITY: 882 Wh
CHARGE TIME: 4 hour charge time
HOUSING: Fully submersible IPX8-rated battery housing system
CONNECTOR: Custom IPX8 battery connector
CHARGER: 48V Grintech battery charger 110/240V AC input
BLUETOOTH: Bluetooth (Bluetooth Standard Ver. 4.1 (2.4GHz band ANT+ wireless communications)
TYPICAL RIDE TIME: 3+ hours on Level 2 assist
Features
Bluetooth Connectivity (GARMIN eBike Remote)
Firmware updates via. custom Android and iOS application
Modular design for ease of transport
Cruising speed 11kph – 13kph (6 mph – 8mph)
Current Top speed 21kph (13mph)
User Interface
GARMIN eBike Remote
Optional: GARMIN watches using Custom Data Field available in GARMIN Connect IQ Store
On/Off button
Increase/decrease electrical assist
Bluetooth (Bluetooth Standard Ver. 4.1 (2.4GHz band))
Product & packaging dimensions
FULLY ASSEMBLED: 1.4 m High x 2 m Wide x 2.2 m Long (4.5 ft High, 6.5 ft Wide, 7.2 ft Long)
WEIGHT: 30.5kg
MAIN BOX: 1510mm x 1050mm x 240mm = 0.381m³ (59.84 x 42.13 x 9.06 = 13.438ft³)
MAIN BOX WEIGHT: 40 kgs (88 lbs)
FOIL BOX: 2040mm x 280mm x 10mm = 0.057m³ (80.51 x 11.02 x 3.54 = 2.017ft³)
FOIL BOX WEIGHT: 4.5kgs (10 lbs)
